WARM-WHITE MATRIX AND RGB ACCENTS

400W Warm White & RGB Matrix LED Strobe Light

400W matrix LED strobe light with thirty 10W warm-white main LEDs and 600 auxiliary 0.3W RGB LEDs. Listed functions include color wash, 1–30Hz strobe, 0–100% linear dimming and DMX512 with RDM. The fixture protection rating is IP20.

30 × 10W warm white
600 × 0.3W RGB / 400W fixture
1–30Hz / RDM / IP20

Get a Quote

MATRIX LED STROBE

400W Warm White RGB Matrix LED Strobe — combine warm-white main light with RGB wash.

400W Warm White RGB Matrix LED Strobe is specified with thirty 10W 3535 warm-white LEDs and 600 auxiliary 0.3W 5050 RGB LEDs. Complete-fixture power is 400W.

Thirty warm-white LEDs

The main-source specification lists thirty 10W warm-white LEDs.

600 RGB LEDs

The auxiliary source uses the listed 5050 RGB LEDs.

Wash and strobe

Specify the RGB wash and main-light flash cues in the scene.

DMX512 with RDM

Provide the console and required RDM workflow.

Specifications

Technical specifications

Model	RG-911
Public product power	400W fixture power
Light source	30 × 10W 3535 warm-white LEDs + 600 × 0.3W 5050 RGB LEDs
Rated fixture power	400W
Voltage	AC 100–240V, 50/60Hz
DMX channels	13CH / 16CH / 23AC / 25CH / 19CH / 23BC / 31CH / 35CH / 51CH / 120CH / 128CH
IP rating	IP20
Control modes	DMX512 with RDM / Auto / Master-Slave / Sound Activated
Pixel control	Warm-white main LED matrix with RGB auxiliary LEDs
Strobe rate	1–30Hz

MAIN AND RGB LIGHT

Specify the two lighting roles.

Describe the warm-white main output and RGB auxiliary wash separately in the lighting brief.

Warm-white main matrixIdentify the desired main-light intensity and flash cues.

RGB auxiliary washProvide the required RGB colors and scene transitions.

Fixture ratingUse the listed 400W complete-fixture power for electrical planning.

DIMMING AND STROBE

Program intensity changes and flash timing.

Dimming is listed at 0–100% linear dimming, with strobe frequency at 1–30Hz.

Linear dimmingDescribe intensity changes within the stated range.

1–30Hz strobeSpecify the desired flash frequency and cue sequence.

Wash and flash cuesInclude how the RGB wash and warm-white main light contribute to the scene.

CONTROL PROFILES

Select the channel chart for the required cues.

Listed DMX mode labels are 13CH, 16CH, 23AC, 25CH, 19CH, 23BC, 31CH, 35CH, 51CH, 120CH and 128CH. Match the selected label to the channel chart.

DMX512 and RDMProvide the console, selected profile and remote-management requirements.

Original profile labelsUse 23AC and 23BC as supplied labels when requesting the corresponding chart.

Playback modesAuto, Master-Slave and Sound Activated are listed alongside DMX512.

HOUSING AND CONNECTIONS

Plan the IP20 installation and cable routing.

The supplied construction is black metal, with an IP20 rating, DMX512 input/output and power input/output. Working temperature is listed at −30°C to 60°C.

IP20 fixtureUse the specified protection rating when planning the installation.

Signal and powerIdentify the required input/output connectors and cable configuration.

Temperature rangeMatch the operating environment to the listed range.

APPLICATION FIT

Plan warm-white matrix and RGB scenes.

Choose the warm-white main LEDs for the primary flash or wash look and the RGB auxiliary LEDs for a separate color layer around it. These are different output roles, not a main RGBW source. Describe the desired white hit and colored background together, then check the selected chart for the required control. IP20 keeps the fixture in dry indoor or suitably protected positions.

Warm-white flash cuesDescribe the main-matrix flash timing and intensity.

RGB wash scenesIdentify the required colors and transitions.

Console programmingProvide the selected DMX mode label, channel chart and RDM requirements.

Power and mountingPlan around 400W fixture power, AC 100–240V input and the IP20 installation.

Explore the LED strobe light range for other source and matrix layouts.

B2B ORDER FLOW

Request the selected fixture configuration.

Identify 400W Warm White RGB Matrix LED Strobe and the source configuration in your inquiry so the offer addresses the required lighting and control setup. For network planning, use ESTA’s DMX512-A guide alongside the fixture’s channel chart.

01 · LIGHTING

Describe the required lighting cues.

Send mounting positions, working distance, warm-white flash or wash requirements, RGB-layer cues, camera use and expected cue duration. Ask for the profile that provides the required controls rather than choosing by channel count alone.

02 · CONTROL

Specify the console and operating profile.

Include the selected channel mode, console, power connections and accessory requirements.

03 · DELIVERY

Complete the supply brief.

State quantity, destination, schedule, mounting accessories and packing configuration for this model.

PRODUCT FAQ

Questions Before You Order.

Sources, optical functions, control and order configuration.

What main and RGB sources are specified?

Thirty 10W 3535 warm-white LEDs and 600 auxiliary 0.3W 5050 RGB LEDs are listed.

What is the complete-fixture power?

RG-911 is specified at 400W fixture power. Source LED ratings are separate component specifications.

What effects and strobe range are listed?

Color wash and flash effects are listed, with a strobe-frequency range of 1–30Hz.

What dimming range is provided?

0–100% linear dimming is specified.

Which DMX mode labels are listed?

13CH, 16CH, 23AC, 25CH, 19CH, 23BC, 31CH, 35CH, 51CH, 120CH and 128CH are listed. Request the matching channel chart; 23AC and 23BC are retained as supplied labels.

What RDM and operating modes are listed?

DMX512 with RDM, Auto, Master-Slave and Sound Activated operation are specified.

What protection, input and connections are specified?

IP20 protection, AC 100–240V at 50/60Hz input, DMX512 input/output and power input/output are listed. Working temperature is −30°C to 60°C.

What should I include in a warm-white RGB matrix strobe inquiry?

Identify RG-911, quantity, fixture positions, warm-white main and RGB wash cues, dimming and strobe timing, console and selected channel chart, RDM workflow, power and signal connections, mounting and packing requirements, destination and schedule.
