24-LED RG-312 PLUS
24-LED IP68 Waterproof PAR Light overview
Specify this version when the requirement is the 24-position RG-312 PLUS face. Choose 4-in-1, 5-in-1 or 6-in-1 by the required color package, and confirm the extra emitters before ordering. The series shares a 200W fixture rating, fan-cooled housing and control platform; LED count alone is not an output comparison.
24 LEDs
A dedicated 24-position front arrangement for this series variant.
4/5/6-in-1 options
Select one source package; the exact additional colors require confirmation.
Fan cooling
The shared rear housing shows a built-in cooling fan.
DMX + standalone
DMX512, Master-slave, Sound and Auto modes are listed.
PRODUCT & EFFECT VIEWS
Review the shared housing, rear controls and color output.
These housing and effect references apply to the RG-312 PLUS series. The 24-LED hero image is specific to this variant.
Specifications
Technical specifications
| Model | RG-312 PLUS 24PCS |
|---|---|
| Public product power | 200W |
| Light source | 24 high-brightness LEDs; 4-in-1, 5-in-1 or 6-in-1 options |
| Voltage | AC 90–245V, 50/60Hz |
| DMX channels | 4-in-1: 8CH; 6-in-1: 6 / 10CH |
| IP rating | IP68 (supplier-provided specification) |
| Product dimensions | 320 × 205 × 240mm |
| Net weight | 4.5kg |
| Control modes | DMX512 / Master-slave / Sound / Auto |
APPLICATION FIT
Match the fixture to the real venue role.
Plan the 24-position version around the target stage or backdrop area and the chosen color package. Check fixture spacing and output at the working distance instead of carrying a brightness assumption over from the 18- or 54-LED versions. Compare related LED PAR lights by source configuration and control needs; confirm the complete outdoor connection plan for the venue.
B2B ORDER FLOW
Prepare a complete quotation brief.
For your 24-LED IP68 Waterproof PAR Light order, send the quantity, destination, selected source configuration, voltage, control workflow, venue conditions, mounting and accessory needs. For DMX network planning, consult ESTA’s DMX512-A guide and request this fixture’s current channel chart.
PRODUCT FAQ
Questions Before You Order.
Direct answers about configuration, control, installation and quotation.
Which front layout does this page cover?
This is the 24-LED front layout. The 18-, 24- and 54-LED versions share the listed 200W rating, housing, fan and control platform. Choose the exact source package and compare output at the same working distance; the LED count alone does not establish which version is brighter.
Which LED packages can be ordered?
The supplied options are 4-in-1, 5-in-1 and 6-in-1; confirm the exact extra colors.
What is the fixture power?
The listed complete-fixture power is 200W.
Which control modes are available?
DMX512, Master-slave, Sound and Auto modes are listed.
Which channel modes are listed?
4-in-1 uses 8CH; the 6-in-1 option lists 6CH or 10CH.
What protection rating is supplied?
IP68 is the supplier-provided fixture rating; request supporting evidence for engineering or tender use.
Does IP68 cover the complete installation?
No. Cable connections, power distribution, mounting and drainage need project-level protection.
What should I include in an inquiry?
Quantity, destination, selected source package, exact colors, voltage, control, venue exposure and accessories.
