Waterproof PAR Light with 7 or 9 RGBW LEDs

IP65 Waterproof PAR Light for Outdoor Stage Lighting

The waterproof PAR light RG-433 is a compact LED wash fixture designed for outdoor stages, festivals, weddings, concerts and event rental projects. Its IP65-rated housing protects the fixture against dust and water jets, making it more suitable for changing outdoor conditions than a standard indoor PAR light.

Buyers can select seven or nine high-power LEDs. The available light-source configurations include RGBW 4-in-1, RGBWA 5-in-1 and RGBWAP 6-in-1 options. Therefore, distributors and project contractors can choose the color system that matches their market and application requirements.

The fixture also supports DMX512, automatic, sound-activated and master-slave operation. This allows it to work in professional programmed systems as well as smaller standalone event setups.

Three LED Color Configurations

The RG-433 offers three light-source configurations:

• 7 or 9 × 10W RGBW 4-in-1 LEDs
• 7 or 9 × 15W RGBWA 5-in-1 LEDs
• 7 or 9 × 15W RGBWAP 6-in-1 LEDs

The RGBW version combines red, green, blue and white output. It provides common stage colors together with a dedicated white channel for cleaner white light and pastel shades.

The RGBWA version adds amber, which helps create warmer colors for weddings, theater scenes and decorative venue lighting.

The RGBWAP version adds further color-mixing capability for projects that require a broader palette. Buyers should confirm the required LED quantity and color configuration before production.

IP65 Protection for Outdoor Events

The IP65 protection rating makes this waterproof PAR light suitable for outdoor stage and event applications. The housing protects internal components against dust and water jets from different directions.

This protection is useful for:

• Outdoor concerts and festivals
• Temporary event stages
• Wedding and banquet lighting
• Hotel and venue exteriors
• Outdoor performance spaces
• Rental lighting inventories
• Covered architectural lighting
• Touring event productions

However, IP65 does not mean that the fixture can operate underwater. Installers should not immerse it or place it where water can accumulate around the connections. Proper outdoor power distribution and installation procedures remain essential.

Flat Housing for Flexible Installation

The flat fixture design takes up less space than a traditional deep PAR can. This makes the light easier to position beside stage scenery, under truss structures, along venue walls or around temporary event installations.

Its listed net weight is approximately 3kg. As a result, rental crews can transport and install multiple units without adding excessive equipment weight.

The compact format also helps distributors and rental companies manage warehouse storage and transport. The listed packing size is 20 × 20 × 23cm, but buyers should confirm final carton dimensions before planning bulk freight or custom flight cases.

8-Channel DMX512 Control

The RG-433 supports an 8-channel DMX mode for integration with professional lighting consoles.

Available control modes include:

• DMX512
• Automatic programs
• Sound-activated operation
• Master-slave synchronization
• 8-channel DMX mode

DMX512 control allows lighting designers to coordinate the PAR light with moving heads, strobes, wash lights and other stage fixtures. Operators can build programmed color changes and effects for concerts, festivals and theater productions.

Sound mode follows music without requiring detailed programming. Automatic mode runs built-in effects, while master-slave mode synchronizes multiple fixtures from one primary unit.

Color Washes for Events and Performances

This IP65 LED PAR light can provide color washes for stage backgrounds, scenery, venue walls, performance areas and decorative structures.

The selectable RGBW, RGBWA and RGBWAP configurations make it suitable for both energetic entertainment lighting and warmer decorative applications. For example, rental companies can use saturated colors during concerts and softer amber-based colors during weddings or formal events.

Several units can be installed together to create continuous color coverage. They can also be divided into DMX groups for alternating colors, chases and synchronized transitions.

Technical Specifications

• Model: RG-433
• Product type: Waterproof flat LED PAR light
• Input voltage: AC 90–240V, 50/60Hz
• Rated power: 120W
• LED quantity: Seven or nine LEDs
• 4-in-1 option: 7/9 × 10W RGBW LEDs
• 5-in-1 option: 7/9 × 15W RGBWA LEDs
• 6-in-1 option: 7/9 × 15W RGBWAP LEDs
• Protection rating: IP65
• DMX channels: 8CH
• Control modes: DMX512, automatic, sound and master-slave
• Net weight: Approximately 3kg
• Listed packing size: 20 × 20 × 23cm
• Installation type: Flat PAR housing
• Recommended environment: Indoor and outdoor stage applications

Recommended Applications

The RG-433 is suitable for:

• Outdoor concert lighting
• Festival and touring stages
• Wedding and corporate events
• Theater and live performance lighting
• Hotels and banquet venues
• Outdoor DJ events
• Event rental inventories
• Stage background washes
• Exhibition and display lighting
• Covered architectural lighting
• Clubs and entertainment venues
• Temporary outdoor installations

Benefits for Rental Companies and Distributors

The RG-433 combines outdoor protection, flexible color options and standard DMX control in a compact product. Rental companies can use it for indoor and outdoor projects, reducing the need to maintain completely separate PAR light inventories.

Distributors can also offer different LED configurations for different customer groups. RGBW provides the standard professional color system, RGBWA supports warmer event colors, and RGBWAP provides broader color-mixing options.

The universal AC 90–240V input supports international markets. Buyers can discuss LED configuration, order quantity, product labels, packing and shipping requirements before production.

Frequently Asked Questions

What makes the RG-433 suitable for outdoor use?

It has an IP65 protection rating, which protects the fixture against dust and water jets.

Is an IP65 PAR light completely waterproof?

It is suitable for outdoor exposure, but it must not be immersed in water. Installers should also use suitable outdoor cables and protected power connections.

Can I choose between seven and nine LEDs?

Yes. The product is available with seven or nine high-power LEDs.

What color configurations are available?

Available configurations include RGBW 4-in-1, RGBWA 5-in-1 and RGBWAP 6-in-1 LEDs.

Does the fixture support DMX512?

Yes. It supports an 8-channel DMX mode.

Can multiple fixtures run without a DMX controller?

Yes. Master-slave mode allows several units to run synchronized effects. Automatic and sound-activated modes are also available.

Is the product suitable for rental companies?

Yes. Its IP65 protection, compact flat housing and multiple operating modes make it suitable for event and stage rental inventories.

How can I request a wholesale quotation?

Provide the required LED quantity, color configuration, order quantity and destination country. WUYESTAGE can then prepare the appropriate product and shipping quotation.
