💥 Product Overview

The RG-763 LED Moving Beam Light is a compact yet powerful pixel beam fixture designed for stages, clubs, concerts, and rental lighting systems. Equipped with 10 pieces of 40W CREE RGBW 4-in-1 LEDs, it delivers intense brightness, vivid color mixing, and sharp narrow beams with excellent penetration.

Featuring individual pixel control, each LED can be programmed independently to create dynamic horse racing effects, flowing chases, and layered beam movements. The integrated Y-axis rotation system enhances motion effects, adding depth and energy to lighting scenes and making performances more visually impactful.

With a narrow 3° optical beam angle, RG-763 produces tight, focused beams ideal for aerial effects and rhythmic lighting designs. Multiple control options including DMX512, auto, master-slave, and sound activation allow seamless integration into both simple and advanced lighting setups.

Built with a durable structure and long-lifespan LEDs rated at up to 50,000 hours, RG-763 is an excellent choice for professional stage applications, touring shows, and rental companies seeking reliability, flexibility, and strong visual impact.

💡 Key Features

• 10×40W CREE RGBW 4-in-1 LED light sources

• Individual pixel control for advanced beam effects

• Built-in horse racing and chase effects

• Y-axis rotation for dynamic movement

• Narrow 3° beam angle with strong beam penetration

• Supports DMX512, Auto, Master-Slave, and Sound control

• Long LED lifespan up to 50,000 hours

• Ideal for stage, club, concert, and rental lighting

📊 Technical Specifications

• Model: RG-763

• Input Voltage: AC95–245V / 50Hz

• Rated Power: 150W

• Light Source:

  • 10 × 40W CREE RGBW 4-in-1 LEDs

• LED Lifespan: Average 50,000 hours

• Beam Angle: 3°

• Strobe: Up to 20 times/second

• Control Modes:

  • DMX512

  • Auto

  • Master-slave

  • Sound activation

• DMX Channels: 5CH / 14CH

• Net Weight: 10 kg

• Fixture Dimensions: 112 × 31 × 35 cm

• Main Effects:

  • Individual pixel beam control

  • Horse racing effects

  • Dynamic Y-axis rotation

🎯 Applications

• Concerts & touring performances

• Nightclubs & DJ stages

• Live events & festivals

• Stage shows & TV studios

• Professional rental lighting systems
