Beam Moving Head Light Overview

Beam moving head light RG-132 combines a 300W lamp with an RGB LED ring and multiple prism effects. It produces a sharp 2° beam for concerts, clubs, wedding stages and event rental projects.

In addition, the fixture includes 14 colors plus white, metal and glass gobos, linear dimming and adjustable strobe effects. Lighting operators can combine these functions to create varied stage programs.

The fixture also supports 18CH and 22CH DMX modes. Therefore, it works with both standard programs and more detailed professional control setups.

Powerful 300W Beam Output

The 300W lamp creates a bright and concentrated beam. Meanwhile, the narrow 2° beam angle helps the light travel across medium and large venues.

As a result, the fixture produces clear aerial effects during concerts, DJ shows and nightclub programs. Stage haze can further improve beam visibility.

The product specifications list a 125 mm optical diameter. Moreover, the rated power reaches 450W, while the wide AC 90–240V input supports different international markets.

RGB LED Ring Effects

RG-132 includes 24 × 0.5W RGB 3-in-1 LEDs around the front lens. The LED ring adds colorful effects around the main beam.

For example, operators can use the ring during scene changes, music transitions or beam movement sequences. It also creates an attractive front-facing effect when the fixture points toward the audience.

In addition, the RGB ring expands the available visual effects without requiring another lighting fixture. This feature gives rental companies more programming options for different events.

Multiple Rotating Prism Effects

This beam moving head light offers several prism combinations. The system includes an 8-facet prism, 8+16 prism, 8+16+24 prism and 6-linear prism.

Furthermore, each prism supports rotation in both directions. Operators can adjust the rotation to create layered, circular or linear beam effects.

For example, the 8+16+24 prism creates a wide multi-beam pattern for energetic concert scenes. In contrast, the linear prism produces a more directional effect for stage sweeps and music accents.

Therefore, one RG-132 fixture can deliver many different beam looks. This flexibility helps rental companies serve weddings, clubs, concerts and touring productions with the same product model.

Color and Gobo System

The color wheel provides 14 colors plus white. It also supports rainbow effects for continuous color changes.

Meanwhile, the fixed gobo wheel includes an open white position, 10 metal gobos and 4 glass gobos. These patterns add texture and shape to the beam.

Operators can combine colors, gobos and prisms through DMX. As a result, they can build complex effects without adding extra fixtures.

Moreover, RG-132 provides 0–100% linear dimming. The strobe system offers speeds from 1 to 25 flashes per second. Therefore, the fixture can support both smooth transitions and fast music-driven effects.

Smooth Pan and Tilt Movement

RG-132 provides 540° pan and 270° tilt movement. The 16-bit movement system helps the fixture reach accurate positions.

In addition, smooth movement improves synchronization when a stage uses several units. Operators can create crossing beams, circular sweeps and coordinated movement sequences.

The fixture responds well to detailed DMX programming. However, users can also select automatic, sound-activated or master-slave operation when a console is unavailable.

Therefore, this moving head beam light works for both professional productions and simpler entertainment installations.

DMX and Standalone Control

The fixture supports 18CH and 22CH DMX modes. The 18-channel mode provides practical control for standard shows. Meanwhile, the 22-channel mode gives programmers access to more detailed functions.

RG-132 also provides four operating options:

• DMX control
• Automatic operation
• Sound activation
• Master-slave operation

For example, a rental company can use DMX mode for a programmed concert. A club can use sound mode for music-based effects. In addition, master-slave mode can synchronize several fixtures without complex programming.

Beam Moving Head Light Applications

This beam moving head light works well in entertainment venues that need sharp aerial beams and dynamic effects.

Typical applications include:

• Concerts and live music stages
• Nightclubs and bars
• Wedding stages and banquet halls
• DJ shows and music festivals
• Touring productions
• Television and performance stages
• Event rental projects
• Indoor stage lighting installations

For example, wedding companies can use the prism effects for entrances and performance moments. Meanwhile, clubs can combine the strobe, RGB ring and sound mode with dance music.

Concert programmers can also synchronize several units through DMX. As a result, they can create large beam arrays across the stage and audience area.

Practical Choice for Rental Companies

RG-132 weighs 9 kg and measures 28 × 23 × 46.5 cm. Therefore, rental teams can transport and install the fixture more easily than larger high-power models.

In addition, the multiple prisms, colors, gobos and operating modes allow one fixture to serve different events. This flexibility can simplify rental inventory planning.

The IP20 rating makes RG-132 suitable for indoor use. However, users must protect it from rain, water and excessive moisture.

The fixture also supports OEM and ODM orders. Distributors can discuss logo printing, labels, packaging and other order requirements before production.

Technical Specifications

Beam Moving Head Light FAQ

What light source does RG-132 use?

RG-132 uses a 300W lamp. In addition, 24 RGB LEDs form a decorative ring around the main lens.

What prism effects does the fixture provide?

The fixture provides an 8-facet prism, 8+16 prism, 8+16+24 prism and 6-linear prism. Moreover, the prisms rotate in both directions.

Which DMX modes does RG-132 support?

RG-132 supports 18CH and 22CH DMX modes. Therefore, users can select a mode that matches their programming needs.

Can rental companies use this fixture?

Yes. The compact size, 9 kg net weight and varied effects suit event rental applications. For example, rental teams can use it for concerts, clubs, weddings and DJ shows.

Can RG-132 operate without a DMX console?

Yes. Users can select automatic, sound-activated or master-slave operation. However, DMX control provides the most detailed programming options.

Can the fixture work outdoors?

RG-132 carries an IP20 rating. Therefore, use it indoors or in a properly protected environment. Do not expose it directly to rain or water.

Wholesale and OEM Orders

WUYESTAGE supplies RG-132 to stage lighting distributors, rental companies, equipment dealers and project contractors. Contact us for the beam moving head light price, MOQ, packaging details, lead time and OEM options.
